HIKVISION DS-2CD4012F-A Installation Manual

Installation Manual of Network Camera
37
 Press RESET about 10s when the camera is powering on or rebooting to restore the default
settings, including the user name, password, IP address, port No., etc.
3.4.2 Installation
 Ceiling Mounting
Steps:
1. Drill the screw holes on the ceiling with the supplied drilling template. If you need to route the
cables from the bottom of the camera, cut a cable hole in the ceiling.
Drill Template
1
1
22
2
2
3
3
3
3
4 4
4
4
Screw hole 3: for
Mounting Base
Hole A: for cables routed
through the ceiling
Code:190600839
Figure 3-34 Drilling Template
2. Secure the back box to the ceiling with screws.
Figure 3-35 Mount Back Box
3. Loosen the set screws with the hex key (supplied) to remove the bubble; remove the black liner.
