HIKVISION ds-2cd8153f-e Technical Manual

Hikvision Technical Manual
©2006 – 2012 by HIKVISION. All rights reserved.
3
DS-2CD8153F-E(I)(W)
Key Features
 Up to 2 megapixel (1600 × 1200) resolution
 Standard video compression with high compression ratio
 Progressive scan CMOS, capture motion video without incised margin
 Support e-PTZ function
 Support dual stream, and the sub-stream for mobile surveillance
 Up to 32 GB Micro SD card for on-board storage
 Built-in microphone and speaker
 Two-way audio
 PoE (Power over Ethernet)
Specification
Model
Parameter
DS-2CD8153F-E(I)(W)
2 megapixel CMOS Network Cube Camera
Camera
Image Sensor
1/3” Progressive Scan CMOS
Min. Illumination
0.5 Lux @ (F1.2, AGC ON), 0.1 Lux @ (F1.2, AGC ON, sensitivity × 5)
1.1 Lux @ (F1.8, AGC ON), 0.2 Lux @ (F1.8, AGC ON, sensitivity × 5)
Shutter Speed
1/25 s to 1/100,000 s
Lens
4 mm @ F1.8
Angle of view:68°
Lens Mount
M12
Day & Night
Electronic
Compression Standard

HIKVISION ds-2cd8153f-e Specifications

General

Brand	HIKVISION
Model	ds-2cd8153f-e
Category	Security Camera
Language	English
