HIKVISION ds-2cd8153f-e Technical Manual

Hikvision Technical Manual
©2006 – 2012 by HIKVISION. All rights reserved.
5
11n: -74dBm (Typical)
Transfer Rates
11b: 11Mbps
11g: 54Mbps
11n: up to 150Mbps
Wireless Range
Outdoor：200m，Indoor：50m（depend on environment）
General
Operating
Conditions
-25 °C – 60 °C (-13 °F – 140 °F)
Humidity 95% or less (non-condensing)
Power Supply
5V DC ± 10%
PoE (802.3af)
Power
Consumption
Max. 4 W
-I: Max. 5 W
-W: Max. 5.5W
IR Range
-I: Approx. 2-5 meters
Dimensions
110 × 70.4 × 47.6 mm (4.33” ×2.77” × 1.87”)
Weight
250 g (0.55 lbs)
* “-W” series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support
the 802.1x protocol.
* “-I” series support 2-5 meters IR Range
* A mount is provided with the camera in the package
Order Models
DS-2CD8153F-E, DS-2CD8153F-EI
DS-2CD8153F-EW,DS-2CD8153F-EIW
Dimensions
Unit: mm

HIKVISION ds-2cd8153f-e Specifications

General

Brand	HIKVISION
Model	ds-2cd8153f-e
Category	Security Camera
Language	English
