7. You can copy your settings to other alarm inputs.
8. Click to save the settings.
Figure 5-18 Linkage Method
5.2.4 Configuring Alarm Output
Steps:
1. Enter the Alarm Output settings interface:
Configuration> Event > Basic Event > Alarm Output
2. Select one alarm output channel in the Alarm Output dropdown list.
3. Set a name in for the alarm output
(optional).
4. The Delay time can be set to 1sec, 5sec, 10sec, 30sec, 1min, 2min, 5min, 10min or Manual.
The delay time refers to the time duration that the alarm output remains in effect after alarm
occurs.
5. Click tab to enter the arming schedule setting interface. The time schedule
configuration is the same as the settings of the arming schedule for motion detection. Refer
to Section 5.2.1 Configuring Motion Detection for more details.
