HIKVISION DS-2DF8A836IX-AEL User Manual

© Hikvision
Figure 6-1 TCP/IP Settings
2. Configure the NIC settings, including the IPv4(IPv6) Address, IPv4(IPv6) Subnet Mask and
IPv4(IPv6) Default Gateway.
3. Click to save the above settings.
You can click Test to make sure that the IP address is valid.
Notes:
 If the DHCP server is available, you can check to automatically obtain an IP
address and other network settings from that server.
 The valid value range of Maximum Transmission Unit (MTU) is 1280 to 1500.
 The Multicast sends a stream to the multicast group address and allows multiple clients to
acquire the stream at the same time by requesting a copy from the multicast group address.
Before utilizing this function, you have to enable the Multicast function of your router and
configure the gateway of the network camera.
 If the DNS server settings are required for some applications (e.g., sending email), you
should properly configure the Preferred DNS Server and Alternate DNS server.
Figure 6-2 DNS Server Settings
Note:
The router must support the route advertisement function if you select Route
Advertisement as the IPv6 mode.

HIKVISION DS-2DF8A836IX-AEL Specifications

General

Camera Type	PTZ
Max Resolution	3840 × 2160
Video Compression	H.265+/H.265/H.264+/H.264
Protection Level	IP66
Day/Night	ICR
Aperture	F1.6 to F4.7
Zoom	16 × Digital
Angle of View	H: 60.7° to 2.2°
Min. Illumination	0 Lux with IR
Pan Range	360°
Tilt Range	-15° to 90°
Pan Speed	0.1° to 300°/s
Tilt Speed	0.1° to 200°/s
Preset	300
Network Interface	RJ45 10M/100M Ethernet
Operating Conditions	-40 °C to 70 °C (-40 °F to 158 °F) Humidity: ≤ 95% (non-condensing)
Dimensions	Φ220 × 340.5 mm
Frame Rate	50 Hz: 25 fps (3840 × 2160), 60 Hz: 30 fps (3840 × 2160)
