Thermal & Optical Bi-spectrum Network Camera User Manual
33
well as the image captured when the alarm is triggered.
Video
Select the video channel and video duration as required.
● 0 s: It will not upload the video of the seletced channel.
● 3 s: Upload the video that is recorded about 1 s before and 2 s after the alarm is
triggered.
● 5 s: Upload the video that is recorded about 2 s before and 3 s after the alarm is
triggered.
● 7 s: Upload the video that is recorded about 2 s before and 5 s after the alarm is
triggered.
6) Input the receiver's information, including the receiver's name and address.
7) Click Test to see if the function is well configured.
3. Click Save.
7.2.4 Notify Surveillance Center
Check Notify Surveillance Center, the alarm information is uploaded to the surveillance center
when an alarm event is detected.
7.2.5 Trigger Recording
Check Trigger Recording, and the device records the video about the detected alarm event.
For device with more than one camera channels, you can set one or more channels to take
recordings if needed.
For recording settings, refer to Video Recording and Picture Capture.
7.2.6 Set Audible Alarm Output
When the device detects targets in the detection area, audible alarm can be triggered as a
warning.
Steps
1. Go to Configuration → Event → Basic Event → Audible Alarm Output.
2. Select an Alarm Type.
3. Select Sound Type and set related parameters.
– Select Warning and its contents. Set the alarm times you need.
– Select Custom Audio. You can select a custom audio file from the drop-down list. If no file is
available, you can click Add to upload an audio file that meets the requirement. Up to six
audio files can be uploaded, and each audio file shall not exceed 512 KB.
4. Optional: Click Test to play the selected audio file on the device.
5. Set arming schedule for audible alarm. See Set Arming Schedule for details.
6. Click Save.
