HIKVISION DS-2TD2637T-7/P Quick Start Guide

DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide
QSG DS-2TD2xxx-xx/xx 071720NA 22
Screw
0°-90°
0°-360°
Figure 27, 2-Axis Adjustment
Install Type III Camera
Before You Start
There are three Type III camera installation methods: wall mounting, ceiling mounting, and stand
mounting.
Wall Mounting Ceiling Mounting Stand Mounting
Figure 28, Type III Camera Installation Methods
Loosen the screws on the junction box cover.
Draw the latches from the latch hole of the junction box and take apart the cover from the junction
box.
