HIKVISION DS-7104NI-Q1/M User Manual

Chapter 9 Web Operaon
9.1 Introducon
You can get access to the video recorder via web browser.
You may use one of the following listed web browsers: Internet Explorer 6.0 to 11.0, Apple Safari,
Mozilla Firefox, and Google Chrome. The supported resoluons include 1024×768 and above.
9.2 Login
You shall acknowledge that the use of the product with Internet access might be under network
security risks. For avoidance of any network aacks and informaon leakage, please strengthen
your own protecon. If the product does not work properly, please contact with your dealer or the
nearest service center.
Steps
1. Open web browser, input the IP address of the video recorder and then press Enter.
Note
If you have changed HTTP port, enter hp://IP address:HTTP port in address bar. E.g., hp:
192.168.1.64:81.
2. Enter user name and password in the login interface.
3. Click Login.
Figure 9-1 Login
4. Follow the installaon prompts to install the plug-in.
Note
You may have to close the web browser to nish the installaon of the plug-in.
Network Video Recorder User Manual
74

HIKVISION DS-7104NI-Q1/M Specifications

General

Input bandwidth	40 Mbit/s
Output bandwidth	60 Mbit/s
Maximum resolution	1920 x 1080 pixels
Video input channels	4 channels
Supported resolutions	1920x1080, 1280x1024, 1280x720, 1024x768
Video recording modes	720p, 1080p
Video formats supported	H.264, H.264+, H.265, H.265+
HDMI output	Yes
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP
Product color	Black
Rack capacity	1U
Wi-Fi	No
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Number of HDDs installed	0
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Output voltage	12 V
Power consumption (max)	18 W

Weight and Dimensions

Depth	225 mm
Width	260 mm
Height	48 mm
Weight	1000 g
