HIKVISION DS-7108NI-Q1/8P/M Quick Start Guide

Network Video Recorder Quick Start Guide
19
Two kinds of record types are introduced in the following section, including Instant Record and
All-day Record. And for other record types, you may refer to the user manual for detailed
information.
After rebooting all the manual records enabled are canceled.
On the live view window, right lick the window and move the cursor to the Start Recording
option, and select Continuous Record or Motion Detection Record on your demand.
Start Recording from Right-click Menu
Click Yes in the pop-up Attention message box to confirm the settings. All the channels will
start to record in the selected mode.
Playback
The recorded video files on the hard disk can be played back in the following modes: instant
playback, all-day playback for the specified channel, and playback by
normal/event/smart/tag/sub-periods/external file search.
Enter playback interface.
Click Menu > Playback or from the right-click menu
Check the checkbox of channel(s) in the channel list and then double-click to select a date on
the calendar.
You can use the toolbar in the bottom part of Playback interface to control playing progress.

HIKVISION DS-7108NI-Q1/8P/M Specifications

General

DC voltage	48 V
Power supply type	DC
Power consumption (typical)	75 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Video input channels	8 channels
USB 2.0 ports quantity	2
VGA (D-Sub) output ports	1
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Maximum HDD capacity	6000 GB
Video compression formats	H.264, H.265

Weight and Dimensions

Depth	225 mm
Width	260 mm
Height	48 mm
Weight	1000 g
