User Manual of Digital Video Recorder
40
4.2.1 Customizing Presets
Purpose:
Follow the steps to set the Preset location which you want the PTZ camera to point to when an event takes
place.
Steps:
1. Enter the PTZ Control interface.
Menu>Camera>PTZ>More Settings
Figure 4. 2 PTZ- More Settings
Use the directional button to wheel the camera to the location where you want to set preset.
Check the checkbox of Save Preset.
Click the preset number to save the preset.
Repeat the steps2-4 to save more presets. If the number of the presets you want to save is more than 17, you
can click […] and choose the available numbers.
Figure 4. 3 More Presets
4.2.2 Calling Presets
Purpose:
The view angle of the PTZ camera will be moved to the predefined position when you call a preset.
Call a preset on the PTZ setting interface:
