DS-7700NI-E4/P
Model
DS-7708NI-E4/8P
DS-7716NI-E4/16P
DS-7732NI-E4/16P
Video/Audio
input
IP video input
8-ch
16-ch
32-ch
Two-way audio
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth
80 Mbps
160 Mbps
160 Mbps
Outgoing bandwidth
80 Mbps
Remote connection
32
128
Video/Audio
output
Recording resolution
6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame rate
Main stream: 50 fps (P)/60 fps (N)
Sub-stream: 50 fps (P)/60 fps (N)
HDMI/VGA output
1-ch, resolution:
1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
Audio output
1-ch, RCA (Linear, 1kΩ)
Decoding
Live view/Playback
resolution
6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability
8-ch@720p,
5-ch@1080p
16-ch@4CIF, 12-ch@720p, 6-ch@1080p
Network
management
Network protocols
TCP/IP, DHCP, PPPoE, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP,
NFS, iSCSI, UPnP™, HTTPS
Hard disk
SATA
4 SATA interfaces for 2 HDDs + 1 DVD-R/W (default), or 4HDDs
eSATA (Optional)
1 eSATA interface
Capacity
Up to 6TB capacity for each HDD
External
interface
Network interface
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Serial interface
RS-232 and RS-485
USB interface
2 × USB 2.0 and 1 × USB 3.0
Alarm in/out
16/4 (optionally can be expanded to 16/8)
PoE
Interface
8 independent 100 Mbps
PoE network interfaces
16 independent 100 Mbps PoE network interfaces
Max. Power
200 W
Supported standard
AF and AT
General
Power supply
100 to 240 VAC
Consumption
(without hard disk,
DVD-R/W or PoE)
≤ 20 W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF )
Working humidity
10 % to 90 %
Chassis
19-inch rack-mounted 1.5U chassis
Dimensions
(W × D × H)
445 × 400 × 71 mm (17.5" × 15.7" × 2.8")
Weight
(without hard disk
or DVD-R/W)
≤ 4 kg (8.82 lb)
