HIKVISION DS-7608NI-E2/8P Quick Start Guide

www.hikvision.com/en/us
Hikvision NVRs are defaulted to CONTINUOUS RECORDING.
Please go to: “MENU”>”RECORDING CONFIGURATION”
7. SETTING UP RECORDING
SETTING UP RECORDING
Setup Recording Schedule
(Continuous/Event)
The color of the calendar is what
constitutes the recording schedule:
1. Blue=Continuous
2. Yellow=Event (Motion/Alarm)
3. Pink=VCA Event
4. Grey= No Recording
Select the camera.
Enable/Disable the schedule
This field is used to
customize a part of the
existing schedule
This can be ignored if
setting up event only
recording
 Please note: If ENABLE SCHEDULE is not
checked, then that camera would not be recording

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
