HIKVISION DS-7608NI-E2/8P Quick Start Guide

www.hikvision.com/en/us
To initiate a PLAYBACK, go to “MENU”>”PLAYBACK”.
Steps to initiate PLAYBACK
1. Select the desired camera
2. Select the desired date. The days that contain recording will be highlighted on the calendar
3. Select the desired time using the Timeline or “Jump to Time” feature.
4. Press “PLAY”
PLAYING BACK RECORDED VIDEO
Select a camera
to playback
Click on the
timeline to select
the desired time
of playback
Select the
desired date to
playback
“Full Screen”
button.
Going to a full
screen will allow
multiple channel
playback
Press PLAY to
begin playback
Select the
desired time of
playback
9. PLAYING BACK RECORDED VIDEO

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
