Network Video Recorder User Manual
94
Note
If the network audio device has linked a network camera, after the audio device is deleted, the
recorder will store audio of the linked network camera itself.
7.2 Configure the Linkage Action and Arming Schedule
Configure the linkage actions and arming schedule for access control or alarm devices. Linkage
actions will be triggered when the designate alarm occurs.
Steps
1. Click of an added IoT device.
Figure 7-4 Configure IoT
2. Select Event Type. The following configuration is only valid for the selected event type.
3. Check Enable.
4. Check linkage actions as your desire. For detailed steps, refer to Configure Linkage Actions.
Note
Full Screen Monitoring and OSD Display are only valid for the selected Trigger Channel.
5. Click Arming Schedule.
6. Configure arming schedule. For detailed steps, refer to Configure Arming Schedule. Linkage
action is only valid during the set schedule.
7. Click Apply.
