HIKVISION DS-K1102 EK Installation Manual

4
2.2 Rear View
Figure 2-2 Rear View of DS-K1106 Series
No.
Name
1
PSAM Card Slot (available for CPU card reader)
2
DIP Switch
3
Cable Interface of RS-485, Power, LED Control, etc.
4
Serial Port
Chapter 3 Installation
3.1 Installing PSAM Card
PSAM card slot is only available for CPU card reader.
Insert the PSAM card into the slot according to the direction
shown below.
