HIKVISION DS-K2601 User Manual

DS-K2600 Series Access Controller
1
Table of Contents
1 Product Description ............................................................................................ 3
1.1 Overview .......................................................................................................................... 3
1.2 Main Feature ................................................................................................................... 3
2 Appearance ........................................................................................................ 5
2.1 Component Description ................................................................................................... 5
2.1.1 Access Controller Component Schematic Diagram ................................................... 5
3 Terminal Connection ........................................................................................... 7
3.1 Terminals Description ...................................................................................................... 7
3.1.1 DS-K2601Terminal Description .................................................................................. 7
3.1.2 DS-K2602Terminal Description ................................................................................ 11
3.1.3 DS-K2604 Terminal Description ............................................................................... 16
4 Card Reader Installation ................................................................................... 22
4.1 External Terminal ........................................................................................................... 22
4.1.1 DS-K2601 External Terminals .................................................................................. 22
4.1.2 DS-K2602 External Terminals .................................................................................. 22
4.1.3 DS-K2604 External Terminals .................................................................................. 22
4.2 Card Reader Installation ................................................................................................ 23
4.2.4 The Connection of Wiegand Card Reader ............................................................... 23
4.2.5 RS485 Card Reader Connection ............................................................................... 24
4.3 Installing E-Lock ............................................................................................................. 25
4.3.1 Installation of Cathode Lock .................................................................................... 25
4.3.2 Installation of Anode Lock ....................................................................................... 25
4.4 Connecting the External Alarm Device .......................................................................... 26
4.5 Door Button Wiring Diagram ......................................................................................... 26
4.6 The Connection of Magnetics Detection ....................................................................... 27
4.7 Connecting Power Supply .............................................................................................. 27

HIKVISION DS-K2601 Specifications

General

Product type	Access controller
Certification	CE, FCC
Product color	Gray
Brand compatibility	Hikvision
Operating temperature (T-T)	-20 - 65 °C

Weight and Dimensions

Depth	370 mm
Width	345 mm
Height	90 mm
