Face Recognition Terminal·Quick Start Guide
22
6.11 Linking Access Control Device
Purpose:
The face recognition terminal can connect to an access control device via RS-232 protocol and
transmit authentication information to the access control device at the same time.
The access control device can control the door status according to authentication result and the
access control device authentication mode, and transmit the door events to the control client or
other systems.
Before you start:
Make sure the access control device has connected to the face recognition terminal via RS-232
protocol.
Make sure the face recognition terminal and the access control device are powered on.
Steps:
1. Set the baud rate of the RS-232 protocol in the COM tab.
Note: The face recognition terminal’s baud rate of RS-232 protocol should be the same as the
access control device’s. For details about setting the baud rate of the RS-232 protocol, see 6.2.2
Setting COM Parameters.
2. Authenticate via the face recognition terminal.
The face recognition terminal will send the authentication result and the card No. to the access
control device. The access control device will control the door status according to the result.
And it will also send the related events to the client or other systems.
Note: For details about access control device’s authentication mode, see the user manual of
the related access control device.
