HIKVISION DS-KH6310-W User Manual

Video Intercom Indoor Station·User Manual
99
Operation Method
Capacitive Touch
Screen, Physical Button
Physical Button
Operation Interface
Flattened UI Operation Interface
Audio Parameters
Audio Input
Build-in Omnidirectional Microphone
Audio Output
Build-in Loudspeaker
Audio Compression
Standard
G.711 U
Audio Compression
Rate
64 Kbps
Audio Quality
Noise Suppression and Echo Cancellation
Network Parameters
Ethernet
10/100 Mbps Self-Adaptive Ethernet
Network Protocol
TCP/IP, SNMP, SIP, RTSP
Alarm Parameters
Alarm Input
2-ch Alarm Input Sensor
Device Interfaces
Network Interface
1 RJ45 10/100 Mbps Self-Adaptive Ethernet
Interface
Other Parameters
Power Supply
DC 24V, Power Over Network Cable (DS-KAD606,
DS-KAD612)
DC 12V
Power Consumption
≤10 W
Working Temperature
-10° C to +55° C (14° F to 131° F)
Working Humidity
10% to 90%
Dimension (L x W x H)
195.8 mm × 132.8 mm × 17.5 mm (7.7" × 5.2"
×0.7")
Certification
FCC, IC, CE, C-TICK, ROHS, REACH, WEEE

HIKVISION DS-KH6310-W Specifications

General

Color	Yes
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Number of buttons	4 buttons
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Display diagonal	7 \
Display resolution	800 x 480 pixels
Display technology	LCD/TFT
Indoor unit power type	AC/DC
Power consumption (typical)	10 W
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C
Proper use	Indoor
Control type	Buttons, Touch
Product color	White
Operating system installed	Linux
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP

Weight and Dimensions

Depth	26 mm
Width	217 mm
Height	142 mm
