HIKVISION DS-PHA48-EP User Manual

102
 = Protocol Setting =
Protocol Type
— ADM-CID
— SIA-DCS
— *ADM-CID
— *SIA-DCS
Select token supported by the receiver in the ARC. Choose the token with “*” mark to
improve the communication security.
 = Server Setting =
 Address Type
— IP
— Domain Name
 Server Address / Domain Name
 Port No.
Input IP address or domain name by which the transceiver of receiving center could be
reached. Input port number of the server provided by the ARC
 = Account Setting =
 Account Code
Input the assigned account provided by the ARC.
 = SIA DC-09 Protocol Setting =
 Transmission Mode
— TCP
— UDP
Both TCP and UDP are supported for transmission. UDP is recommended by the SIA DC-09

HIKVISION DS-PHA48-EP Specifications

General

2G standards	GSM
Number of alarm zones	48
Alert notification type	SMS
Connectivity technology	Wired & Wireless
Mobile network generation	4G
Smartphone remote support	Yes
Number of simultaneous users	48 user(s)
Control type	-
Mounting type	Wall
Product color	White
Housing material	Plastic
Number of door/window sensors	- pc(s)
Battery life	36 h
Input voltage	100 - 240 V
Battery voltage	13.5 V
Battery capacity	7000 mAh

Weight and Dimensions

Alarm control panel weight	996.5 g
Alarm control panel dimensions (W x D x H)	261 x 86.4 x 261 mm
