HIKVISION iDS-TCM403-B/0832 Configuration Manual

Violaon Detecon
Type
Descripon
When the number of pedestrians not yielded to reaches the set
value, capture will be triggered.
1.5.2 Set Linked Lane Parameters
You can set the properes and parameters of the linked lanes.
Steps
Note
●
Not all the applicaon modes support linked lane parameters sengs.
●
The linked lane parameters vary with dierent models. The actual device prevails.
1.
Go to Conguraon → Capture → Applicaon Mode .
2.
Select Applicaon Mode.
3.
Set lane parameters.
Lane No.
The No. of the selected lane.
Linked Lane No.
The corresponding lane No. linked with the current lane. The lane No. will be overlaid on the
captured picture.
Lane Type
If you select Highway Emergency Lane or Truck Forbidden Lane, set the period.
If you select Opposite Lane, the lane
direcon will be opposite from the current direcon.
Total Lanes
The sum of the linked lane(s) under the current applicaon mode.
Lane Direcon
The guidance direcon of the lane.
Lane Property
Select the lane type for speeding capture. The violaon rules vary with dierent lane types.
Direcon (in Mixed-Trac Lane Mode and Smart Mode)
The driving direcon of the vehicle. If you set the direcon as From Top to Boom, then the
vehicle will be judged as wrong-way driving if it comes from
boom to top, and vice versa.
Direcon (in Video Analysis E-Police Mode)
The vehicles on the selected direcon will be detected.
Network Trac Camera Conguraon Manual
22
