HIKVISION Network Video Recorder Quick Operation Guide

Quick Operation Guide of DS-7600NI-SE&V(P) Series NVR
8
Specifications
Specifications of DS-7600NI-SE
Model
DS-7604NI-SE
DS-7608NI-SE
DS-7616NI-SE
Video/Audio
input
IP video input
4-ch
8-ch
16-ch
Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Bandwidth
Incoming
bandwidth
20Mbps
40Mbps
80Mbps
Output
bandwidth
40Mbps
Video/Audio
output
Decoding
resolution
5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/
2CIF/CIF/QCIF
HDMI/VGA
output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 ×
720 /60Hz, 1024 × 768 /60Hz
CVBS
1-ch, BNC (1.0 Vp-p, 75 Ω)
Resolution: 704 × 576 (PAL); 704 × 480 (NTSC) (optional)
Audio output
1-ch, RCA (Linear, 1kΩ).
Playback
resolution
5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF
Synchronous
playback
4-ch, 720P / 2-ch,
1080P / 1-ch, 5MP
8-ch 4CIF /4-ch, 720P / 2-ch, 1080P / 1-ch,
5MP
Hard disk
SATA
1 SATA interface for
1 HDD
2 SATA interfaces for 2 HDDs
Capacity
Up to 4TB for each disk
External
interface
Network
interface
1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface
Serial interface
1 RS-485 half-duplex interface
USB interface
2 × USB 2.0
Alarm in/out
4/1 (optional)
Others
Power supply
12V DC
Consumption
≤ 10 W (without hard disk)
Working
temperature
-10 ºC ~ +55 ºC (14 ºF ~ 131 ºF )
Working
humidity
10 % ~ 90 %
Chassis
Stand-alone 1U
chassis
19-inch rack-mounted 1U chassis
Dimensions
(W × D × H)
315 × 230 × 45mm
(124.0 × 90.5 × 17.7
inch)
445 × 290 × 45mm (175.2 × 114.2 × 17.7 inch)
Weight
≤ 2 Kg (4.4 lb) (without hard disk)
