English 7
PSA 85 PSA 86 PUA 86 19V
Charging temperature
0 ℃ …45 ℃
(32 ℉ …113 ℉)
0 ℃ …40 ℃
(32 ℉ …104 ℉)
5 ℃ …40 ℃
(41 ℉ …104 ℉)
Weight
0.54 kg
(1.19 lb)
0.5 kg
(1.1 lb)
0.52 kg
(1.15 lb)
5 Operation
5.1 Inserting the battery 2
1. If the following equipment exists, also take this action:
PSA 80
▶ Hold the battery end cap so that it is facing you and the large groove on the battery is on the left.
▶ Slide the battery into the battery compartment.
▶ Turn the end cap clockwise until it engages.
2. If the following equipment exists, also take this action:
PSA 81
▶ Push the battery in until it engages securely.
▶ Check that the battery is securely seated in the tool.
3. If the following equipment exists, also take this action:
PSA 82
▶ Insert the battery at an angle into the battery compartment.
▶ Push the battery into the battery compartment until it is heard to engage.
▶ Check that the battery is securely seated in the tool.
4. If the following equipment exists, also take this action:
PSA 83
▶ Insert the end of the battery in the battery compartment.
▶ Push the battery into the battery compartment until it is heard to engage.
▶ Push the small slider on the back toward the battery compartment.
▶ Check that the battery is securely seated in the tool.
5.2 Removing the battery 3
1. If the following equipment exists, also take this action:
PSA 80
▶ Turn the end cap counterclockwise.
▶ Remove the battery from the tool.
Note
Remove the battery only when the tool is switched off. Data may otherwise be lost.
2. If the following equipment exists, also take this action:
PSA 81
▶ Press the catch together.
▶ Remove the battery.
Note
Remove the battery only when the tool is switched off. Data may otherwise be lost.
Printed: 29.09.2017 | Doc-Nr: PUB / 5070488 / 000 / 07
