Hirschmann RS30 series User Manual

64
Installation RS20/22/30/32/40
Release 05 12/2015
7 Technical data
 General technical data
Dimensions
B × H × T
RS20-0400...
RS20-08..., RS20-09..., RS30-0802
RS20-16..., RS20-17..., RS30-1602
RS20-24..., RS20-25..., RS30-2402
RS40-0009CCCCS...
RS40-0009CCCCE...,
RS40-0009CCCCT...
1.85 in. × 5.16 in. × 4.37 in.
(47 mm × 131 mm × 111 mm)
2.91 in. × 5.16 in. × 4.37 in.
(74 mm × 131 mm × 111 mm)
4.33 in. × 5.16 in. × 4.37 in.
(110 mm × 131 mm × 111 mm)
4.33 in. × 5.16 in. × 4.37 in.
(110 mm × 131 mm × 111 mm)
2.91 in. × 5.16 in. × 4.37 in.
(74 mm × 131 mm × 111 mm)
4.33 in. × 5.16 in. × 4.37 in.
(110 mm × 131 mm × 111 mm)
RS22-08..., RS22-09..., RS32-0802
RS22-16..., RS22-17..., RS32-1602
RS22-24..., RS22-25..., RS32-2402
3.54 in. × 5.39 in. × 4.53 in.
(90 mm × 137 mm × 115 mm)
4.72 in. × 5.39 in. × 4.53 in.
(120 mm × 137 mm × 115 mm)
4.72 in. × 5.39 in. × 4.53 in.
(120 mm × 137 mm × 115 mm)
PoE power supply unit RPS
90/48V LV
PoE power supply unit RPS
90/48V HV
2.36 in. × 5.39 in. × 4.53 in.
(60 mm × 137 mm × 115 mm)
2.36 in. × 5.39 in. × 4.53 in.
(60 mm × 137 mm × 115 mm)
Weight RS20-0400...
RS20-08..., RS20-09..., RS30-0802
RS20-16..., RS20-17..., RS30-1602
RS20-24..., RS20-25..., RS30-2402
RS40-0009CCCCS...
RS40-0009CCCCE...,
RS40-0009CCCCT...
14.11 oz (400 g)
14.46 oz (410 g)
21.16 oz (600 g)
20.90 oz (650 g)
18.70 oz (530 g)
21.16 oz (600 g)
RS22-08..., RS22-09..., RS32-0802
RS22-16..., RS22-17..., RS32-1602
RS22-24..., RS22-25..., RS32-2402
28.92 oz (820 g)
40.57 oz (1150 g)
42.33 oz (1200 g)
PoE power supply unit RPS
90/48V LV
PoE power supply unit RPS
90/48V HV
27.16 oz (770 g)
26.10 oz (740 g)
Power supply
RS20-..., RS30-...,
RS40-...
Nominal voltage AC 24 V
Max. voltage range AC 18 V ... 30 V
(incl. max. tolerances)
Rated voltage range DC 12 V ... 48 V
Max. voltage range DC 9.6 V ... 60 V (incl. max. tolerances)
Connection type 6-pin terminal block with snap lock
Power loss buffer > 10 ms
Back-up fuse Nominal rating:
Characteristic:
3.5 A
slow blow
Peak inrush current < 14 A
