HIPER-Ring

Redundancy L2E

Release

4.1

03/08

2.2

Configuring HIPER-Ring Version 2 (MRP

2.2 Configuring HIPER-Ring

Version 2 (MRP Draft)

Note: Before you connect the redundant line, you must complete the

configuration of HIPER-Ring Version 2.

You thus avoid loops during the configuration phase.

Note: Configure each HIPER-Ring device.

 Set up the network to meet your requirements.

 Select the Redundancy:HIPER-Ring dialog.

 Select Version 2 (MRP Draft).

 For each device, you enter the desired ring ports 1 and 2.

The following settings are required for the ring ports (select the

Basic Settings:Port Configuration dialog):

Bit rate 100 Mbit/s 1000 Mbit/s

Autonegotiation

(automatic configuration)

Off On

Port On On

Duplex Full –

Table 3: Port settings for ring ports

Note: When using 100 Mbit/s with twisted pair cables, avoid the combi-

nation of autonegotiation “off” and cable crossing “automatic”. Use

crossover cables with 100 Mbit/s.
