Getting Started
10
Front View and Controls
Item Description
1 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
2 POWER LED
Illuminates blue when the TV is in standby mode and flashes for a few seconds
when you turn on/off the TV.
3 POWER ON/OFF Turn the TV power ON or OFF .
4 MENU Displays the OSD (on screen display) menu.
5 SOURCE
Toggle between all the input sources. In the OSD menu, use this button as you
would use the OK button on the remote control.
3D spectacle synchronized signal transmission window.
6 VOL
Adjust the volume.
Select sub-menu and adjust setting in OSD menus.
7 CH
3D emitter
Change the channels.
Select items of OSD menu.
8
9
Turn the TV standby ON or OFF.
4
8
7
5
6
1
3
9
2
Note：fast power or standby off and on may bring abnormal display on panel. Restart can make it normal.
Interval of 15s between off and on is recommended.
