14
Filter
Check and clean the filter regularly, at least two or three times a year (see
"Removing the filter section)."
Do not use flammable fluids for cleaning the appliance.
.
.
year.
Especially:
If the appliance is not draining properly or if it fails to perform spin cycles.
If the pump is blocked by a foreign body (e.g. buttons, coins or safety pins).
.
.
Removing the Filter
We recommend that you check and clean the filter regularly, at least twice or three
times a
IMPORTANT: Ensure that the water has cooled before draining the appliance.
.
Stop the appliance and unplug it.
Depending on the model, remove the plinth by holding it tightly on both
sides, pushing it downward and tilting it to the front. Or, push down on
the tabs provided on both the sides and remove it .(Fig. "a")
Place a container beneath it.
Wait until all the water has drained.
1
2
3
4
5
Now unscrew the filter completely and remove it (Fig. "b").
Check that the pump rotor moves freely.
6
7
8
9
Clean the filter and the filter chamber.
a
d
e
Detergent dispenser
downward and remove the drawer (Fig. "d").
Remove the cover grid from the fabric softener
compartment.
Remove the separator from the main wash compartment
by pulling it upward (Fig. "e").
Wash all the parts under running water.
Refit the separator and the grid in the detergent drawer
and fit the drawer back inside its housing.
Press the release lever in the main wash compartment
.
.
.
.
.
13
Water supply hose
Check the supply hose regularly for brittleness and cracks and
replace it if necessary using a new hose of the same type
(available from After-Sales Service or specialist dealer).
Mesh filter for water connection
Check and clean regularly.
For washing machines with an inlet hose as shown on
Fig."f ".
f
Close the tap and loosen the inlet hose on the tap.
Clean the internal mesh filter and screw the water inlet hose back onto the tap.
.
.
Now unscrew the inlet hose on the rear of the washing machine.
.
.
Refit the mesh filter and screw the inlet hose on again.
Turn on the tap and ensure that the connections are completely water-tight.
.
.
Pull of the mesh filter from the washing machine connection with universal pliers
Open the filter but do not remove it completely. Slowly turn the filter
counterclockwise until
all the
water has drained.
b
Pour about 1 litre of water into the detergent drawer to check that the filter is
inserted properly and securely.
.
10
11
Reinstall the plinth.
12
Re-insert the filter and screw it in clockwise as far as it will go.
To re-insert the filter make sure the small lug/clip(as shown in the Fig."c")is
facing up and then push the filter into the hosing first. After that start screwing
the filter in clockwise as far as it will go(Fig."c").
Plug in the appliance once again.
Select a programme and start it.
13
14
c
