PARTS LIST
Part No. I.D. Description Size Qty
327441 0001 Clamp-Cord 2
327442 0002 Table Lock Handle 1
327443 0003 Column Ass’y 1
327444 0004 Motor Pulley Ass’y 1
327445 0005 Base 1
327446 0006 Worm 1
327447 0007 Crank Handle Ass’y 1
327448 0008 Rack 1
327449 0009 Rack Ring Ass’y 1
327450 0010 Shifter Knob 1
327451 0011 Spring 1
327452 0012 Retaining Ring 3AMI-14 1
327453 0013 Shifter Bolt 1
327454 0014 Motor Base 1
327455 0015 Feed Shaft Ass’y 1
327456 0016 Hex Hd. Bolt M8*1.25-20 4
327457 0017 Spring Cap Ass’y 1
327458 0018 Pin 1
327459 0019 Quill Set Screw 1
327460 0020 Spindle Ass’y 1
327461 0021 Driving Sleeve Ass’y 1
327462 0022 Pointer 1
327463 0023 Table Ass’y 1
327464 0024 Spindle Pulley 1
327465 0025 Rivet 1
327466 0026 Switch Box 1
327467 0027 Switch Cover 1
327468 0028 Head 1
327469 0029 Knob 1
327470 0030 External Tool M4 1
Lock Washer
Part No. I.D. Description Size Qty
327471 0031 V-Belt O-762 1
327472 0032 Spring Washer M6 4
327473 0033 Hex Hd. Bolt M6*10-12 4
327474 0034 Flat Washer M8 10
327475 0035 Flat Washer M6 4
327476 0036 Hex Hd. Bolt M8*1.25-25 2
327477 0037 CR. RE. Truss Hd. M4*1.6-12 3
Tapping Screw
327478 0038 Cr. Re. Pan Hd. Screw M5*0.8-10 3
327479 0039 Cr. Re. Pan Hd. Screw M5*0.8-15 3
327480 0040 Cr. Re. Pan Hd. Screw M6*1.0-8 3
327481 0041 Cr. Re. Pan Hd. Screw M4*0.7-8 1
327482 0042 Spacer 4
327483 0043 Hex Nut M10*1.5-8 2
327484 0044 Hex Nut M5*0.8 2
327485 0045 Hex Nut M8*1.25 2
327486 0046 External Tool M5 1
Lock Washer
327487 0047 Grommet 4
327488 0048 Chuck & Key RJ33-16L 1
327489 0049 Spring Washer M5 1
327490 0050 Flat Washer M5 6
327491 0051 Power Cable 1
327492 0052 Pulley Cover 1
327493 0053 Rocker Switch 1
327494 0054 Motor 1
327495 0055 Clamp Cord 2
327496 0056 Capacitor 1
327497 0057 Feed Handle 3
327498 0058 Laser Guide Ass’y 1
0059 Set Screw M8*8 2
10″ BENCH DRILL PRESS MODEL NO. B13F
ALWAYS ORDER BY PART NO. AND I.D. NUMBER.
PARTS LIST FOR SCHEMATIC A
– 55 –
