Hitachi C 12RSH2 User Manual

12
English
SPECIFICATIONS
Item Model C 12RSH2
Motor Type Series commutator motor
Power source Single-phase AC 60Hz
Voltage (Volts) 120
Full-load current (Amp) 15
Laser Marker Maximum output
<1mW CLASS
Laser Product
Wave length 400 – 700 nm
Laser medium Laser Diode
Applicable saw
blade
Outside Dia. 12" (305 mm)
Hole Dia. 1" (25.4 mm)
No load speed 4,000/min
Max.
sawing
dimension
Head Turntable Max. sawing dimension
Miter 0 0
*
Max. Height
Max. Width
or
Max. Height
Max. Width
4-3/16" (107 mm)
12-1/4" (312 mm)
4-11/16" (120 mm)
10-3/16" (260 mm)
With aux. board 1" (25 mm)
0 Left 45°
or
Right 45°
*
Max. Height
Max. Width
or
Max. Height
Max. Width
4-3/16" (107 mm)
8-5/8" (220 mm)
4-11/16" (120 mm)
7-1/16" (180 mm)
With aux. board 1" (25 mm)
0Right 57°
*
Max. Height
Max. Width
or
Max. Height
Max. Width
4-3/16" (107 mm)
6-11/16" (170 mm)
4-3/4" (120 mm)
5-1/8" (130 mm)
With aux. board 1" (25 mm)
Bevel Left 45° 0
*
Max. Height
Max. Width
or
Max. Height
Max. Width
2-3/4" (70 mm)
12-1/4" (312 mm)
2-15/16" (75 mm)
10-3/16" (260 mm)
With aux. board 1" (25 mm)
Right 45° 0
*
Max. Height
Max. Width
or
Max. Height
Max. Width
1-3/4" (45 mm)
12-1/4" (312 mm)
1-15/16" (50 mm)
10-3/16" (260 mm)
With aux. board 1" (25 mm)
Compound Left 45° Left 45°
*
Max. Height
Max. Width
or
Max. Height
Max. Width
2-3/4" (70 mm)
8-5/8" (220 mm)
2-15/16" (75 mm)
7-1/16" (180 mm)
With aux. board 1" (25 mm)
Left 45° Right 31°
*
Max. Height
Max. Width
or
Max. Height
Max. Width
2-3/4" (70 mm)
10-7/16" (265 mm)
2-15/16" (75 mm)
8-11/16" (220 mm)
With aux. board 1" (25 mm)
Right 45° Right 45°
*
Max. Height
Max. Width
or
Max. Height
Max. Width
1-3/4" (45 mm)
8-5/8" (220 mm)
1-15/16" (50 mm)
7-1/16" (180 mm)
With aux. board 1" (25 mm)
Right 45° Left 31°
*
Max. Height
Max. Width
or
Max. Height
Max. Width
1-3/4" (45 mm)
10-7/16" (265 mm)
1-15/16" (50 mm)
8-5/8" (220 mm)
With aux. board 1" (25 mm)
Miter sawing range Left 0° – 45° Right 0° – 57°
Bevel sawing range Left 0° – 45° Right 0° – 45°
Compound sawing range Left (Bevel) 0° – 45°, Left (Miter) 0° – 45°, Right (Miter) 0° – 31°
Right (Bevel) 0° – 45°, Right (Miter) 0° – 45°, Left (Miter) 0° – 31°
Net weight 59.5 lbs. (27 kg)
Cord 2 Conductor type cable 6ft. (1.8 m)
