15
English
3. Releasing the locking pin
When the power tool is prepared for
shipping, its main parts are secured by a
locking pin.
Move the handle slightly so that the locking
pin can be disengaged.
NOTE: Lowering the handle slightly
will enable you to disengage
the locking pin more easily and
safely.
The lock position of the locking
pin is for carrying and storage
only.
4. Installing the dust bag, holder, stopper and vises
(The holder and stopper are optional accessories.)
Attach the dust bag and vise assembly as indicated in Fig. 1 and Fig. 2.
BEFORE USING
1. Make sure the power source is appropriate for the tool.
WARNING: Never connect the power tool unless the available AC power
source is of the same voltage as that specifi ed on the nameplate
of the tool.
Never connect this power tool to a DC power source.
2. Make sure the trigger switch is turned OFF.
WARNING: If the power cord is connected to the power source with the
trigger switch turned ON the power tool will start suddenly and
can cause a serious accident.
3. Check the saw blade for visible defects.
Confi rm that the saw blade is free of cracks or other visible damage.
4. Confi rm that the saw blade is attached securely to the power tool.
Using the supplied 17 mm wrench, tighten the 10 mm bolt on the saw blade spindle to
secure the saw blade.
For details, see Fig. 50-a, Fig. 50-b, Fig. 50-c and Fig. 50-d in the section on “SAW BLADE
MOUNTING AND DISMOUNTING”.
Pull
Locking pin
Handle
Fig. 6
0000BookC12RSH2.indb150000BookC12RSH2.indb15 2016/03/0118:07:302016/03/0118:07:30
