-12-
Models Measuring points Allowable level
C 6SS, C 7SS 150 0.3 mm max.
8. Tightening torque values for selected fasteners
• Bolt (W/Washer) M7 x 17.5 [14] ------------------------------------- 9.8 r 2.0 N•m (100 r 20 kgf•cm)
• Seal Lock Screw (W/Sp. Washers) M6 x 14 [62] --------------- 2.9 r 0.5 N•m (30 r 5 kgf•cm)
• Seal Lock Flat Hd. Screw M5 x 12 [4] ----------------------------- 3.4 r 0.7 N•m (35 r 7 kgf•cm)
• Seal Lock Flat Hd. Screw M3 x 12 [9] ----------------------------- 1.8 r 0.4 N•m (18 r 4 kgf•cm)
• Machine Screw (W/Washers) M5 x 45 [15] ---------------------- 3.4 r 0.7 N•m (35 r 7 kgf•cm)
• Screw (W/Washers) M5 x 16 [24] ---------------------------------- 3.4 r 0.7 N•m (35 r 7 kgf•cm)
• Hex. Hd. Tapping Screw D5 x 55 [42] ----------------------------- 2.9 r 0.5 N•m (30 r 5 kgf•cm)
• Tapping Screw (W/Flange) D4 [16], [41] -------------------------- 2.0 r 0.5 N•m (20 r 5 kgf•cm)
• Brush Cap [34] ---------------------------------------------------------- 0.7 r 0.2 N•m (7.5 r 2.5 kgf•cm)
• Hex. Socket Set Screw M5 x 8 [29] -------------------------------- 0.7 r 0.2 N•m (7.5 r 2.5 kgf•cm)
• Flat Hd. Screw M6 x 20 [47] ----------------------------------------- 0.7 r 0.2 N•m (7.5 r 2.5 kgf•cm)
Upon the completion of disassembly and repair, measure the insulation resistance and conduct a dielectric
strength test.
Insulation resistance: 7M or more using a DC 500 V megohm tester
Dielectric strength: AC 4000 V/1 minute, with no abnormalities
The allowable deflection level of the saw blade shall be as follows:
When the unit becomes soiled, use a clean, soft rag moistened with soapy water to clean it. Never use
chloric solvents, gasoline or thinner (which tend to damage plastic material) for cleaning.
Deflection of saw blade
Cleaning the case
Insulation Tests
