Hitachi C 6SS User Manual

-2-
1. Specifications
Model C 6SS C 7SS
Saw blade diameter 165 mm (6-1/2") 190 mm (7-1/2")
at 90° 0 to 57 mm (0 to 2-1/4") 0 to 68 mm (0 to 2-11/16")
Cutting depth
at 45° Max. 38 mm (1-1/2") Max. 46 mm (1-13/16")
Power source AC single phase 50/60 Hz
Type of motor AC single phase commutator motor
Type of switch Trigger switch
Housing
Handle cover
Lower guard
Polycarbonate resin
Gear cover Cast aluminum
Enclosure
Base Cast aluminum / Sheet steel
*
1
Voltage (V) 110 120 220 230 240
*
1
Current (A) 9.6 9.2 5.0 4.8 4.6
Power input 1,010W 1,050W
No-load Rotation speed 5,600/min. 5,900/min. 5,950/min. 5,650/min.
Aluminum
base
3.2 kg (7.1 lbs.) 3.4 kg (7.5 lbs.)
*
2
Net
Steel base 3.1 kg (6.8 lbs.) 3.3 kg (7.3 lbs.)
Aluminum
base
4.0 kg (8.8 lbs.) 4.3 kg (9.5 lbs.)
Weight
Gross
Steel base 3.9 kg (8.6 lbs.) 4.2 kg (9.3 lbs.)
Packaging Corrugated cardboard box / Plastic case and corrugated cardboard sleeve
Type Two-core cabtire cable
Cord
Overall length 2 m (6.6 ft.)
Standard equipment
Tungsten carbide tipped (TCT) saw blade ------------------------------------- 1
Parallel guide -------------------------------------------------------------------------- 1
Hex. bar wrench ---------------------------------------------------------------------- 1
Case (GBR only) ----------------------------------------------------------------------1
*
1
Check the tool name plate to confirm the rating, as it is subjected to change by area.
*
2
The net weight does not include the cord and the saw blade.
SPECIFICATIONS

Hitachi C 6SS Specifications

General

Brand	Hitachi
Model	C 6SS
Category	Saw
Language	English
