Hitachi C 7SB3 User Manual

-10-
White
White
Stator coil
Stator coil
Switch
White
Black
Power
source
Armature
White
White
Stator coil
Stator coil
Switch
White
Black
Power
source
Armature
Noise
suppressor
Ferrite core
Noise
suppressor
Ferrite core
Blue
Blue
Stator coil
Stator coil
Switch
Blue
Brown
Power
source
Armature
Connect the wires as illustrated in the diagrams below.
Be sure to connect the wires correctly. If the wires are incorrectly connected, the motor may not turn or
other problems could occur.
Wiring diagram
• Connecting and wiring diagrams for the USA, Canada, and Mexico (120 V)
• Connecting and wiring diagrams for the UK (110 V)
Noise suppressor
• Connecting and wiring diagrams for New Zealand, Australia, and Europe (230-240 V)
Noise suppressor
Ferrite core
Ferrite core
5±1
5±1
5±1
