Apply specified amount of grease to the following portions.
Grease (JF-375)
• Inner hole of the metal of the Gear Cover [26] ························································· About 0.5 g
Grease (SEP-3A)
• Pinion tooth flank of the Armature [22] ··································································· About 1 g
• Gear tooth flank of the Spindle and Gear Set [1] ······················································ About 1 g
• Inside the gear chamber of the Gear Cover [26] ······················································ About 5 g
Prepare the following grease as necessary.
Item Registered part name Net weight Code No.
Grease (SEP-3A)
Grease (SEP-3A) (100 g) 100 g 930035
Grease (SEP-3A) (2.5 kg) 2.5 kg 930038
Location Name of screw or bolt
No.
used
Tightening torque
N•m lbf-ft
Main body
[2] Bearing Holder [3] Seal Lock Flat Hd. Screw M5 x 14 2 2.7 - 4.1 2.0 – 3.0
[12] TCT Saw Blade [14] Hex. Socket Hd. Bolt M8 x 15.5 1 7.8 - 11.8 5.8 – 8.7
[9] Bearing Cover [15] Seal Lock Flat Hd. Screw M4 x 10 2 1.4 - 2.2 1.0 – 1.6
[16] Lever [15] Machine Screw (W/Washers) M4 x 12 (Black) 1 1.4 - 2.2 1.0 – 1.6
[27] Flow Guide (A) [15] Machine Screw (W/Washers) M4 x 12 (Black) 1 0.8 - 1.2 0.6 – 0.9
[25] Flow Guide (B) [24] Tapping Screw (W/Flange) D4 x 20 (Black) 1 1.4 - 2.2 1.0 – 1.6
[26] Handle Cover [24] Tapping Screw (W/Flange) D4 x 20 (Black) 5 1.5 - 2.5 1.1 – 1.84
[44] Cord Holder [24] Tapping Screw (W/Flange) D4 x 20 (Black) 1 1.5 - 2.5 1.1 – 1.84
[28] Cushion [29] Flat Hd. Screw M6 x 20 1 —
*1
—
*1
[40] Housing Ass'y [38] Machine Screw (W/Washers) M5 x 50 (Black) 3 2.7 - 4.1 2.0 – 3.0
[41] Brush Holder [39] Hex. Socket Set Screw M5 x 8 2 0.5 - 1.0 0.4 – 0.74
[42] Carbon Brush [43] Brush Cap 2 0.5 - 1.5 0.4 – 0.74
[45] Switch [46] Tapping Screw (W/Flange) D4 x 12 2 1.5 - 2.5 1.1 – 1.84
Base ass'y
[58] Lever [57] Lock Nut 1 1.4 - 2.0 1.0 – 1.5
[67] Base [60] Seal Lock Screw (W/Sp. Washer) M4 x 14 1 1.4 - 2.2 1.0 – 1.6
[64] Step Pin D6 x 13 [61] Seal Lock Hex. Socket Set Screw M5 x 6 2 2.7 - 4.1 2.0 – 3.0
*1: Tighten the Flat Hd. Screw M6 x 20 [29] until it is flush with the Cushion [28].
Lubrication points and type of lubricant
Screw tightening torque
