Hitachi M 12VC User Manual

--- 4 ---
M 12VC/SC
1/2" collet chuck .......................................................................................1
1/4" collet chuck .......................................................................................1
23 mm wrench .........................................................................................1
16 mm wrench .........................................................................................1
Template guide adapter ........................................................................... 1
Template guide centering adjuster ...........................................................1
KM 12VC/SC
1/2" collet chuck .......................................................................................1
1/4" collet chuck .......................................................................................1
23 mm wrench .........................................................................................1
16 mm wrench .........................................................................................1
10 mm wrench .........................................................................................1
Template guide adapter ........................................................................... 1
Template guide centering adjuster ...........................................................1
Template guide (porter cable type) .......................................................... 7
Chip shield ...............................................................................................1
Diameter of large sub base ...................................................................... 1
Case ......................................................................................................... 1
5. SPECIFICATIONS
Collect chuck capacity
Type of motor
No-load
Full-load
Weight
1/2" and 1/4"
Single-phase AC commutator motor
7.3 lbs. (3.3 kg) with fixed base
9.9 lbs. (4.5 kg) with plunge base
Enclosure
Head cover (B)
Housing, stator holder, head cover (A)
Model
M 12VC, M 12SC, KM 12VC, KM 12SC
Single-phase AC 60 Hz
120 V, 11 A
Speed
8,000 to 24,000/min. (M 12VC, KM 12VC)
24,000/min. (M 12SC, KM 12SC)
Standard accessories
Nylon resin
Diecast aluminum alloy
(silver metal plating)
•••••••••••••••••••••••••••••••••••••••••••••••
Type of power source
Voltage and input
Insulation method
Single insulation
•••••••••••••
Main body stroke
66 mm (2.6") (Plunge base type)
8,000 to 23,000/min. (M 12VC, KM 12VC)
23,000/min. (M 12SC, KM 12SC)
