English
15
WARNING
WARNING
Magazine (A)
Groove
Nail Strip
ADJUSTING AIR PRESSURE
● Do not exceed 120 psi
(8.3 bar, 8.5 kgf/cm
2
).
Adjust the air pressure at recommended operating pressure 70 – 120 psi (4.9 – 8.3 bar, 5 –
8.5 kgf/cm
2
) according to the length of nails and the hardness of workpiece.
The correct air pressure is the lowest pressure which will do the job. Using the Nailer at a
higher than required air pressure unnecessarily over stresses the Nailer.
LOADING NAILS
● When loading nails into Nailer,
1) do not pull trigger;
2) do not depress push lever; and
3) keep Nailer pointed downward.
(1) 1 Raise the magazine stopper lightly
and pull the lever.
2 Pull the magazine (B) out.
(2) Set nail strip into the magazine (A) and
keep the points of nails in contact with
Groove.
Magazine Stopper
Magazine (B)
Lever
To Next Page
