Hitachi RAS-3WHVRP Technical Catalogue

2 General data
Electrical data
TCGB0123 rev.2 - 10/2019
54
2.6 Electrical data
2.6.1 Considerations
Keywords:
• U: Power supply.
• PH: Phase.
• IPT: Total input power.
• STC: Starting current: Less than maximum current.
• RNC: Running current.
• MC: Maximum current.
? NOTE
• Heating conditions: Inlet/outlet water temperature: 30/35 ºC; Outdoor ambient temperature (DB/WB): 7/6 ºC.
• The compressor data shown in the tables below are based on a combined capacity of 100% of the power supplied.
• The “Maximum current” shown in the above table is the maximum total unit running current at the following conditions:
- Supply voltage: 90% of the rated voltage.
- Unit capacity: 100% at maximum operating conditions.
• The power supply cables must be sized to cover this maximum current value.
• Specications in these tables are subject to change without notice in order that HITACHI may bring the latest innovations to their
customers.
• Please refer to the general information, cautions and notes regarding protective devices (CB, ELB) throughout the
“9.3 Electrical connection” chapter.
2.6.2 Split system - Outdoor unit
RAS-(2-3)WHVRP in combination with YUTAKI S, YUTAKI S COMBI
Model Power supply
Applicable voltage
Compressor and fan motors
MC
(A)
Max.
IPT
(kW)
Cooling Heating
U max.
(V)
U min.
(V)
RNC
(A)
IPT
(KW)
RNC
(A)
IPT
(KW)
RAS-2WHVRP
1~ 230V 50Hz 253 207
4.5 1.00 5.0 1.09 10.4 2.27
RAS-2.5WHVRP 5.0 1.12 5.5 1.19 12.9 2.82
RAS-3WHVRP 7.6 1.67 8.1 1.79 15.8 3.49
2.6.3 Split system - Indoor unit
2.6.3.1 YUTAKI S
RWM-(2.0-3.0)NRE(-W)
Model
Power
supply
Applicable
voltage
Operation mode
RNC
(A)
IPT
(kW)
MC
(A)
Max.
IPT
(kW)
U max.
(V)
U min.
(V)
RWM-(2.0-3.0)
NRE(-W)
1~ 230V
50Hz
253 207
Without electric heater 0.2 0.05 0.2 0.05
With electric heater 13.3 3.05 14.6 3.05
With DHW tank heater 13.3 3.05 14.6 3.05
With electric and DHW tank heaters 26.3 6.05 28.9 6.05
? NOTE
The data corresponding to DHW tank heater is calculated in combination with the domestic hot water tank accessory
“DHWT-(200/300)S-3.0H2E”.
