Hitachi RAS-3WHVRP Technical Catalogue

3 Capacity and selection data
YUTAKI S COMBI
TCGB0123 rev.2 - 10/2019
60
3.2 YUTAKI S COMBI
3.2.1 Maximum heating capacity table (kW) (Integrated)
Ambient temperature (ºC WB)
-20 -15 -10 -7 -2 2 7 12 15 20 25
System
Water
outlet
temp
(ºC)
CAP
(kW)
IPT
(kW)
CAP
(kW)
IPT
(kW)
CAP
(kW)
IPT
(kW)
CAP
(kW)
IPT
(kW)
CAP
(kW)
IPT
(kW)
CAP
(kW)
IPT
(kW)
CAP
(kW)
IPT
(kW)
CAP
(kW)
IPT
(kW)
CAP
(kW)
IPT
(kW)
CAP
(kW)
IPT
(kW)
CAP
(kW)
IPT
(kW)
RAS-2WHVRP
+
RWD-2.0NRW(S)E-(200/260)S(-K)(-W)
60
3.20 2.29 3.64 2.25 4.00 2.22 5.00 2.17 5.50 1.77 5.66 1.71 5.93 1.61 6.20 1.51
55
4.00 2.42 4.20 2.27 4.48 2.25 4.70 2.24 6.00 2.22 6.30 1.80 6.46 1.68 6.73 1.48 7.00 1.27
50
4.36 2.32 4.60 2.22 4.85 2.13 5.05 2.05 6.15 2.01 6.65 1.71 6.85 1.61 7.17 1.43 7.50 1.25
45
4.00 2.35 4.25 2.30 4.72 2.22 5.00 2.17 5.22 2.00 5.40 1.86 6.30 1.80 7.00 1.63 7.23 1.54 7.62 1.38 8.00 1.23
40
4.15 2.34 4.54 2.24 4.93 2.14 5.17 2.08 5.32 1.86 5.45 1.70 6.40 1.59 7.25 1.48 7.48 1.42 7.87 1.31 8.25 1.21
35
4.30 2.32 4.50 2.14 5.02 2.04 5.33 1.98 5.42 1.73 5.49 1.53 6.50 1.38 7.50 1.34 7.73 1.30 8.12 1.24 8.50 1.18
30
4.50 2.23 4.80 2.09 5.31 1.93 5.62 1.83 5.69 1.65 5.75 1.50 6.70 1.34 7.75 1.30 7.98 1.27 8.37 1.20 8.75 1.14
25
4.70 2.14 5.10 2.04 5.60 1.82 5.90 1.68 5.95 1.56 6.00 1.46 6.90 1.30 8.00 1.27 8.23 1.23 8.62 1.16 9.00 1.09
20
4.90 2.04 5.40 1.99 5.89 1.71 6.18 1.54 6.22 1.48 6.25 1.43 7.10 1.26 8.25 1.24 8.48 1.19 8.87 1.12 9.25 1.05
RAS-2.5WHVRP
+
RWD-2.5NRW(S)E-(200/260)S(-K)(-W)
60
4.00 3.33 4.72 3.27 5.30 3.21 6.20 2.58 6.50 2.24 6.66 2.25 6.93 2.27 7.20 2.29
55
4.70 3.13 5.00 2.94 5.44 2.81 5.80 2.70 7.00 2.64 7.50 2.42 7.73 2.34 8.12 2.21 8.50 2.07
50
5.10 2.97 5.40 2.85 5.90 2.74 6.30 2.66 7.48 2.60 8.00 2.27 8.31 2.22 8.83 2.14 8.75 1.85
45
4.60 2.86 5.00 2.86 5.50 2.80 5.80 2.76 6.36 2.68 6.80 2.62 7.97 2.57 8.50 2.12 8.62 2.01 8.81 1.82 9.00 1.64
40
4.80 2.77 5.27 2.77 5.73 2.71 6.01 2.67 6.51 2.54 6.90 2.44 8.28 2.28 8.85 1.95 9.00 1.84 9.25 1.66 9.50 1.48
35
5.00 2.77 5.40 2.77 5.92 2.65 6.23 2.58 6.66 2.40 7.00 2.26 8.60 2.00 9.20 1.77 9.39 1.67 9.70 1.50 10.01 1.33
30
5.25 2.72 5.70 2.72 6.12 2.53 6.36 2.41 6.82 2.25 7.18 2.12 8.85 1.93 9.50 1.67 9.63 1.59 9.84 1.44 10.05 1.29
25
5.50 2.67 6.00 2.67 6.31 2.40 6.50 2.24 6.97 2.10 7.35 1.99 9.10 1.86 9.80 1.58 9.87 1.50 9.98 1.38 10.10 1.25
20
5.75 2.57 6.30 2.57 6.51 2.32 6.63 2.17 7.13 2.00 7.52 1.87 9.35 1.79 10.10 1.49 10.11 1.42 10.13 1.31 10.15 1.20
RAS-3WHVRP
+
RWD-3.0NRW(S)E-(200/260)S(-K)(-W)
60
5.10 3.64 5.77 3.46 6.31 3.32 7.50 3.21 8.00 2.76 8.12 2.73 8.31 2.70 8.50 2.66
55
5.30 3.53 5.50 3.44 6.42 3.42 7.15 3.40 9.00 3.30 9.80 3.11 9.85 3.07 9.92 3.01 10.00 2.94
50
5.80 3.39 6.08 3.31 6.83 3.24 7.43 3.18 9.15 3.08 9.90 2.91 10.03 2.88 10.24 2.83 10.45 2.78
45
5.25 3.39 5.70 3.35 6.30 3.24 6.67 3.18 7.24 3.06 7.70 2.96 9.30 2.86 10.00 2.70 10.21 2.68 10.55 2.66 10.90 2.63
40
5.63 3.36 6.19 3.27 6.75 3.17 7.08 3.12 7.64 2.96 8.09 2.83 10.15 2.77 10.75 2.60 10.88 2.59 11.09 2.56 11.30 2.53
35
6.00 3.33 6.25 3.29 7.03 3.14 7.50 3.06 8.04 2.85 8.47 2.69 10.99 2.68 11.50 2.50 11.55 2.49 11.62 2.46 11.70 2.44
30
6.25 3.29 6.52 3.23 7.23 3.08 7.65 3.00 8.36 2.77 8.94 2.58 11.15 2.57 11.65 2.32 11.70 2.30 11.77 2.26 11.85 2.22
25
6.50 3.25 6.80 3.16 7.42 3.02 7.80 2.94 8.69 2.68 9.40 2.48 11.30 2.46 11.80 2.15 11.85 2.11 11.92 2.06 12.00 2.00
20
6.75 3.21 7.08 3.10 7.62 2.97 7.94 2.88 9.09 2.62 10.00 2.40 11.50 2.40 12.00 2.00 12.16 1.97 12.43 1.92 12.70 1.87
? NOTE
• CAP: Capacity at compressor maximum frequency. Capacity is valid for difference between water inlet and water outlet of 3-8ºC.
• IPT: Total input power.
The table above shows the input power (IPT) at maximum capacity (CAP). Most of the time, the unit will run at partial load, so that the
actual input power will be lower.
