SJ300 Inverter
xiii
Input
Vol tage
Motor
Output
400V
Inverter Model
Wire Size Range (AWG)
Torque
HP kW ft-lbs (N-m)
400V
1 0.75 SJ300-007HFU/E 20 1.1 1.5
2 1.5 SJ300-015HFU/E 18 1.1 1.5
3 2.2 SJ300-022HFU/E 16 1.1 1.5
5 4.0 SJ300-040HFU/E 14 1.1 1.5
7.5 5.5 SJ300-055HFU/E 12 1.8 2.5
10 7.5 SJ300-075HFU/E 10 1.8 2.5
15 11 SJ300-110HFU/E 8 3.6 4.9
20 15 SJ300-150HFU/E 6 3.6 4.9
25 18.5 SJ300-185HFU/E 6 3.6 4.9
30 22 SJ300-220HFU/E 4 3.6 4.9
40 30 SJ300-300HFU/E 3 3.6 4.9
50 37 SJ300-370HFU/E 1 3.6 4.9
60 45 SJ300-450HFU/E 1 AWG (75°C) 6.5 8.8
75 55 SJ300-550HFU/E 1/0 || 1/0 AWG 6.5 8.8
100 75 SJ300-750HFU/E 3/0 (1/0 || 1/0 AWG) 6.5 8.8
125 90 SJ300-900HFU/E 3/0 (1/0 || 1/0 AWG) 10.1 13.7
150 110 SJ300-110HFU/E 1/0 || 1/0 AWG 10.1 13.7
175 132 SJ300-1320HFE 3/0 || 3/0 10.1 13.7
200 150 SJ300-1500HFU 3/0 || 3/0 10.1 13.7
