SJ300 Inverter

Appendix B

B–9

The data in the receive frame contains 8-byte values for 13 items, listed in the table below:

The eight bytes for intelligent input or intelligent output data have a bit set in the data field for

each I/O point that is ON, according to the following table:

No. Monitor Item Units Multiplier

1 Output frequency Hz 100

2 Output current A 10

3 Direction of rotation — —

4 PID feedback monitor % 100

5 Intelligent input monitor — —

6 Intelligent output monitor — —

7 Frequency converting monitor — 100

8 Output torque monitor % 1

9 Output voltage monitor V 10

10 Electric power monitor kW 10

11 Reserved — —

12 Run Mode time monitor hours 1

13 Power ON time monitor hours 1

Terminal Monitor Item Data

[FW] Forward input 00000001

[1] Input 1 00000002

[2] Input 2 00000004

[3] Input 3 00000008

[4] Input 4 00000010

[5] Input 5 00000020

[6] Input 6 00000040

[7] Input 7 00000080

[8] Input 8 00000100

[AL] Alarm relay 00000001

[11] Output 1 00000002

[12] Output 2 00000004

[13] Output 3 00000008

[14] Output 4 00000010

[15] Output 5 00000020
