“A” Group: Standard Functions
Configuring Drive
Parameters
3–12
“A” Function
Run
Mode
Edit
Lo Hi
Defaults
Units
SRW Display
Func.
Code
Name Description
–FE
(EU)
–FU
(US)
–FR
(JP)
A005 [AT] selection Two options; select codes:
00 Select between [O] and
[OI] at [AT]
01 Select between [O] and
[O2] at [AT]
✘ ✘ 00 00 00 —
>A005 AT
SELECT O/OI
A006 [O2] selection Four options; select codes:
00 No summing, [O2] and
[OI]
01 Sum of [O2] and [OI],
neg. sum (reverse speed
reference) inhibited
02 Sum of [O2] and [OI],
neg. sum (reverse speed
reference) allowed
03 Disable [O2] input
✘ ✘ 03 03 03 —
>A006 O2
SELECT O2
A011 [O]–[L] input active
range start frequency
The output frequency corre-
sponding to the voltage input
range starting point
Range is 0.00 to 400.00 Hz
✘ ✔ 0.00 0.00 0.00 Hz
>A011 INPUT-O
EXS 0000.00Hz
A012 [O]–[L] input active
range end frequency
The output frequency corre-
sponding to the voltage input
range ending point
Range is 0.00 to 400.00 Hz
✘ ✔ 0.00 0.00 0.00 Hz
>A012 INPUT-O
EXE 0000.00Hz
A013 [O]–[L] input active
range start voltage
The starting point for the
voltage input range
Range is 0 to 100%
✘ ✔ 0. 0. 0. %
>A013 INPUT-O
EX%S 000%
A014 [O]–[L] input active
range end voltage
The ending point for the
voltage input range
Range is 0 to 100%
✘ ✔ 100. 100. 100. %
>A014 INPUT-O
EX%E 100%
A015 [O]–[L] input start
frequency enable
Two options; select codes:
00 Use A011 start value
01 Use 0 Hz
✘ ✔ 01 01 01 —
>A015 INPUT-O
LEVEL 0Hz
A016 External frequency filter
time constant
Range n = 1 to 30, where n =
number of samples for avg.
✘ ✔ 8. 8. 8. Sam-
ples
>A016 INPUT
F-SAMP 08
To Next Page
