This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise to
about the middle of the gauge. In
severe driving conditions, the pointer
may rise to the upper zone. If it
reaches the red (hot) mark, pull
safely to the side of the road. For
instructions and precautions on
checking the engine’s cooling
system, see page .
This shows how much fuel you
have. It may show slightly more
or less than the actual amount.
523
Gauges
Temperature Gauge
Fuel Gauge
80
U.S. model is shown.
SPEEDOMETER
FUEL GAUGE
TEMPERATURE GAUGETACHOMETER
INFORMATION DISPLAYSELECT/RESET KNOB
SPEEDOMETER
FUEL GAUGE
TEMPERATURE GAUGE
SELECT/RESET KNOB
Touring models
Except Touring models
TACHOMETER
MULTI-INFORMATION DISPLAY
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.
０８／０３／１０ １７：３８：３７ ３１ＳＺＡ６００ ００８５
