Honda CRF450R 2013 User Manual

Optional Parts List
158 Technical Information
Optional Parts List
These parts and tools may be ordered from your
authorized dealer.
FRAME Remarks
Driven sprocket < >: Drive chain links
48 Teeth, Aluminum.
<116>
Standard
Optional 47 Teeth, Aluminum
49 Teeth, Aluminum
Drive chain
size/link
D.I.D 520 DMA4/120RB
RK520TXZ/120RJ
Handlebar
lower holder
0.1 in (3 mm) offset
Optional no offset
TOOLS Remarks
Pin spanner A To adjust spring preload.
(two spanners required)
Workstand For maintenance
Air gauge For checking tire air pressure and
PSF air pressure
FRAME Remarks
Shock spring 308.3 lbf/in (54 N/mm)
Standard
(Medium)
Optional
296.9 lbf/in (52 N/mm)
Soft
Stiff 319.8 lbf/in (56 N/mm)
Pink paint
Yellow paint
White paint

Honda CRF450R 2013 Specifications

General

Engine Type	449cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	96.0mm x 62.1mm
Compression Ratio	12.5:1
Induction	PGM-FI, 46mm throttle body
Transmission	Close-ratio five-speed
Final Drive	#520 Chain; 13T/48T
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	120/80-19
Wheelbase	58.7 inches
Seat Height	37.6 inches
Fuel Capacity	1.7 gallons
Ground Clearance	13.0 inches
Front Suspension	48mm inverted Kayaba PSF (Pneumatic Spring Fork) with air-adjustable spring rate, rebound and compression damping adjustability; 12.2 inches travel
Rear Suspension	Pro-Link single shock with adjustable spring preload, rebound and compression damping adjustability; 12.4 inches travel
Trail	4.6 inches
