General| Engine Type | 449cc liquid-cooled single-cylinder four-stroke |
|---|---|
| Bore x Stroke | 96.0mm x 62.1mm |
| Compression Ratio | 12.5:1 |
| Induction | PGM-FI, 46mm throttle body |
| Transmission | Close-ratio five-speed |
| Final Drive | #520 Chain; 13T/48T |
| Front Brake | Single 240mm disc with twin-piston caliper |
| Rear Brake | Single 240mm disc |
| Front Tire | 80/100-21 |
| Rear Tire | 120/80-19 |
| Wheelbase | 58.7 inches |
| Seat Height | 37.6 inches |
| Fuel Capacity | 1.7 gallons |
| Ground Clearance | 13.0 inches |
| Front Suspension | 48mm inverted Kayaba PSF (Pneumatic Spring Fork) with air-adjustable spring rate, rebound and compression damping adjustability; 12.2 inches travel |
| Rear Suspension | Pro-Link single shock with adjustable spring preload, rebound and compression damping adjustability; 12.4 inches travel |
| Trail | 4.6 inches |
