Honda CRF450R 2013 User Manual

Fuel Tank
(cont’d)
Servicing Your Honda 35
12. Pull the fuel tank (14) out of the frame and
hang it to the left of the frame.
Check the fuel tank stopper cable (15) for
deterioration, kinks or other damage.
Do not support the fuel tank by the fuel feed hose
(12).
13. Check for interference between the frame and
tank and adjust the cushion rubbers (16) if
necessary.
Installation
1. Install the fuel feed hose (1) to the clamp (2) if
it is removed.
2. Install the fuel tank (3) on the frame.
3. Install the collar and fuel tank bolt (4).
4. Hook the air cleaner rubber (5) and the fuel
tank band (6).
WARNING
Gasoline is highly flammable and
explosive.You can be burned or seriously
injured when handling fuel.
• Stop the engine and keep heat, sparks
and flame away.
• Handle fuel only outdoors.
• Wipe up spills immediately.
(12) fuel feed hose (15) fuel tank stopper cable
(14) fuel tank
(12)
(14)
(15)
(16) cushion rubbers
(16)
2.2 in (55 mm)
(1) fuel feed hose (2) clamp
(3) fuel tank
(4) collar and fuel tank bolt
(5) air cleaner rubber
(6) fuel tank band
(1)
(2)
(6)
(5)
(4)
(3)

Honda CRF450R 2013 Specifications

General

Engine Type	449cc liquid-cooled single-cylinder four-stroke
Bore x Stroke	96.0mm x 62.1mm
Compression Ratio	12.5:1
Induction	PGM-FI, 46mm throttle body
Transmission	Close-ratio five-speed
Final Drive	#520 Chain; 13T/48T
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	120/80-19
Wheelbase	58.7 inches
Seat Height	37.6 inches
Fuel Capacity	1.7 gallons
Ground Clearance	13.0 inches
Front Suspension	48mm inverted Kayaba PSF (Pneumatic Spring Fork) with air-adjustable spring rate, rebound and compression damping adjustability; 12.2 inches travel
Rear Suspension	Pro-Link single shock with adjustable spring preload, rebound and compression damping adjustability; 12.4 inches travel
Trail	4.6 inches
