Specifications
■ Main Components
Overall length
E, VII E, ED, VI ED
type
2,145 mm (84.4 in)
V E, IV ED type
2,170 mm (85.4 in)
Overall width 754 mm (29.7 in)
Overall height
1,495 mm (58.9 in)
(Windscreen highest position)
Wheelbase 1,505 mm (59.3 in)
Minimum ground
clearance
141 mm (5.6 in)
Caster angle 26°30’
Trail 91 mm (3.6 in)
Curb weight
E, VII E, ED, VI ED
type
164 kg (362 lb)
V E, IV ED type
166 kg (366 lb)
Maximum weight
capacity
*1
180 kg (397 lb)
Maximum luggage
weight
*2
Total 19 kg (42 lb)
Luggage box 10 kg (22 lb)
Glove box 1.5 kg (3.3 lb)
V E, IV ED type
Rear carrier
5.0 kg (11.0 lb)
*1 : Including rider, passenger, all luggage, and accessories.
*2 : Includes the weight of the luggage and added accessories.
Passenger capacity
Rider and 1 passenger
Minimum turning radius 2.30 m (7.5 ft)
Displacement 125 cm
3
(7.6 cu-in)
Bore x stroke
53.5 x 55.5 mm (2.11 x 2.19 in)
Compression ratio 11.5:1
Fuel
Unleaded petrol
Recommended: 95 RON or higher
Fuels containing alcohol ETHANOL up to 10 % by volume
Tank capacity 11.7 L (3.09 US gal, 2.57 Imp gal)
Battery
YTZ8V
12 V-7 Ah (10 HR) / 7.4 Ah (20 HR)
Primary reduction
V-Matic (2.79:1 ~ 0.82:1)
Final reduction 10.552
Specifications
143
