Removing & Installing Body Components u Headlight Case
52
Headlight Case
#
Removal
1.
Pull up the rubber dust covers.
2.
Loosen the lock nuts by turning clockwise.
3.
Loosen the rearview mirrors and remove
them by turning them clockwise until they
will no longer turn.
4.
Loosen the mirror adapters by turning
counterclockwise and remove them.
Rubber dust covers
Lock nut
Lock nut
Rearview mirrors
Mirror
adapter
Mirror
adapter
17 AFB110MD MS (PH)-32K89C000.book Page 52 Tuesday, February 21, 2017 9:38 AM
