Model 5496 Intelligent Power Module Installation and Operation Manual 151276-L8
2-2
2.4 5496 Board and Terminal Strip Description
Figure 2-1 shows the 5496 circuit board including location of terminals and the
dipswitch for setting the module ID.
Figure 2-1 The 5496 Board Layout
DIP switches for
Setting ID
To AC
Regulated
SBUS Module
Connections
Battery
Connections
Output Circuits
All Circuits
Supervised Power
limited, except
Battery and AC
which are
supervised non-
power limited.
