HAWK 8000 CONTROLLER – INSTALLATION & COMMISSIONING INSTRUCTIONS
Manufactured for and on behalf of the Environmental & Energy Solutions Division of Honeywell Technologies Sàrl, Rolle, Z.A. La Pièce 16, Switzerland by its Authorized Representative:
CentraLine
Honeywell GmbH
Böblinger Strasse 17
71101 Schönaich, Germany
Phone +49 (0) 7031 637 845
Fax +49 (0) 7031 637 740
info@centraline.com
www.centraline.com
Subject to change without notice
EN1Z-1016GE51 R0218
SPECIFICATIONS
Power
Voltage: 24 VAC/DC (50/60 Hz)
Max. power consumption: 18 VA (without Expansion
Modules);
20 VA (fully loaded with
Expansion Modules)
Rec. power supply: 24 VAC (24 VA) / 24 VDC (1 A)
Environmental Specifications
Operating temperature: -20 … +60 °C
Storage temperature: -40 … +85 °C
Humidity: 5 … 95%, non-condensing
Shipping and vibration: ASTM D4169, Assurance Level II
MTTF: +10 years
Dimensions: See Fig. 3 to Fig. 5.
APPROVALS, CERTIFICATIONS, ETC.
▪ UL 916, Energy Management Equipment – Edition 4
▪ CE: 2014/53/EU RED, 2011/65/EU RoHs
▪ FCC Part 15, Subpart B, Class B; Part 15, Subpart C
▪ C-UL listed to Canadian Standards Assoc. (CSA) C22.2
No. 205-M1983 "Signal Equipment"
▪ Ethernet: IEEEC 802.3
▪ Purpose of the device is: multifunctional non-safety control
intended for HVAC in home (residential, commercial, and
light-industrial) environments
NOTE: Keep AC mains supply/load cables separate from
signal wiring!
RELATED TECHNICAL LITERATURE
Table 11. Related Technical Literature
Title
Product
Literature no.
HAWK 8000 – Installation & Comm. Instructions EN1Z-1016GE51
HAWK 8000 – Product Data EN0Z-1016GE51
HAWK 8000 – Mounting Instructions MU1Z-1016GE51
HAWK 8000 – Installation & Startup Guide EN1Z-1027GE51
HAWK 8000 – Backup & Restore Guide EN2Z-1027GE51
HAWK 8000 – PICS EN0Z-1028GE51
HAWK 8000 – WiFi Guide EN2Z-1029GE51
HON-NXEM-xxx Expansion Modules – M.I. MU1Z-1031GE51
Panel Bus I/O Modules – Product Data EN0Z-0979GE51
