KRA 405B RADAR ALTIMETER INSTALLATION MANUAL
Page 1-10
006-10536-0010 Rev. 10 Oct/2005
B. RADAR ALTIMETER INDICATOR - Honeywell KNI 415 or KNI 416
TABLE 1-1 KNI 415/416 INDICATOR AVAILABILITY
C. RADAR ALTIMETER ANTENNAS (2 each)
Honeywell KA 54A, Part Number 071-1501-00 (White)
Part Number 071-01501-0100 (Black)
Gaskets are included with a new antenna. They may be ordered
separately as P/N 187-01753-0000.
NOTE: The KA 54 Radar Altimeter Antenna is compatible with the
KRA 405B and may be used in retrofit situations. However,
this antenna is no longer available from the factory.
D. KRA 405B INSTALLATION KIT
P/N 050-03365-00XX which includes the following:
UNIT PART NUMBER FACEPLATE PANEL LIGHTING
KNI 415 066-3031-00 BLACK 5 VOLT
KNI 415 066-3031-01 BLACK 28 VOLT
KNI 415 066-3031-02 GRAY 5 VOLT
KNI 415 066-3031-03 GRAY 28 VOLT
KNI 415 066-3031-04 BLACK NIGHT VISION
KNI 416 066-3044-00 BLACK 5 VOLT
KNI 416 066-3044-01 BLACK 28 VOLT
KNI 416 066-3044-02 GRAY 5 VOLT
KNI 416 066-3044-03 GRAY 28 VOLT
KNI 416 066-3044-04 BLACK NIGHT VISION
PART NUMBER DESCRIPTION UM -00 -01 -02 -03 VENDOR PART NUMBER
030-02077-0000 41 Pin Conn Solder EA 1100CANNON KPT06B2041S
030-02077-0004 41 Pin Conn Crimp EA 0011CANNON KPSE06F20-41S
057-05944-0017 TSO KIT LABEL EA 1000N.A.
057-05944-0018 TSO KIT LABEL EA 0100N.A.
057-05944-0019 TSO KIT LABEL EA 0010N.A.
057-05944-0020 TSO KIT LABEL EA 0001N.A.
071-04003-0000 Mounting Rack EA 1010
