– 32 –
USER FUNCTIONS
USER FUNCTIONSUSER FUNCTIONS
USER FUNCTIONS
Scheduling User Interface
To access the Scheduling User Interface enter: + FUNCTION + [64]
Master user code or
Installer Code
The system will initially display “Set Schedule” followed by the programming prompts as shown below.
Note that all inputs are checked for validity upon entry. The keypad will beep two times for invalid
data entries and all invalid entries are rejected. When the [*] key is depressed, the system will beep
once and advance to the next field. Not all of the fields are used for each of the event identifiers. When
the system reaches the final prompt for the specific event identifier and the [*] key is depressed, the
system will accept and save the entire schedule event. The system will beep four times and return to
initial programming field (Schedule Number) and the schedule number will be advanced. If the current
schedule number is 8, the system will return to schedule number to 1. Depressing the [#] key will reject
the entry and back up one field. If the [#] key is depressed while in the “Schedule Number” screen, the
system will exit the schedule programming mode.
NOTES: 1. During the schedule programming mode, if three minutes have passed and no key has been entered, the
programming will be terminated and no values will be saved.
2. If a zone is troubled while in schedule programming, the system will abort the programming mode and
show the troubled zone, and any uncompleted program event will not be saved.
3. It is not possible to enter the schedule programming mode from a wireless keypad. Pressing any key on
a wireless (RF) keypad terminates Schedule programming mode.
4. It is not possible to enter the Schedule programming mode if FC or CA is displayed.
x n
Schedule Number
Schedule Number
Enter the 1-digit schedule number to be programmed, then press [*] to accept
and advance to the Event Identifier field. (x = schedule number)
NOTES: 1. Press the [#] key in this entry will exit the schedule programming mode. The
keypad will beep four times and exit.
2. Schedule number 7 and 8 are always random events that are meant to work
only with X10 devices. This option should be implemented when the User is
trying to give the impression that a premises is “lived in”. The events will occur
at random times (0-59 minutes) within the defined hour.
Selections
1 to 8
[*] = Accept entry and continue
[#] = Exit schedule programming mode
